| A1 | Total length with standard attachment | 4,050 mm |
| B1 | Wheel base center | 1,525 mm |
| C1 | Rear overhang | 1,140 mm |
| D2 | Height with canopy down | 2,020 mm |
| D3 | Height with cab | 2,170 mm |
| D4 | Height with cab lowered | 2,020 mm |
| D10 | Total height with rotating beacon | 2,490 mm |
| E1 | Max. height blade pivot point | 2,800 mm |
| F1 | Load-over height | 2,680 mm |
| G1 | Dumping height | 2,290 mm |
| I1 | Digging depth | 60 mm |
| J1 | Total width | 1,240 mm |
| J2 | Track width | 970 mm |
| L1 | Turning radius outer edge wheels | 2,000 mm |
| M1 | Steering angle | 38 ° |
| M2 | Swing angle | 14 ° |
| N1 | Dumping angle at max. lifting height | 40 ° |
| O1 | Dumping angle at ground level | 43 ° |
| P1 | Distance center front axle to tooth tip | 1,390 mm |
| Q1 | Bucket width | 1,250 mm |
| R1 | Stacking height | 2,630 mm |
5035
