8145T

Teleskopické kolesové nakladač 8145T

Sériová výbava

  • Comfortable, spacious cabin
  • Interior lighting with door contact switch; entrance and exit on both sides
  • Cabin inspected according to ROPS and FOPS; windshield wipers front and rear, front and back with intermittent wipers
  • Telescoping and adjustable tilting steering column
  • Joystick console (fold-down)
  • Mechanically-sprung operator's seat (MSG85/722) with automatic seat belt; weight, back and twin horizontal adjustment
  • 7” LCD display with integrated rear-view camera
  • Electronically pilot-operated multifunction joystick with integrated travel direction selector for use at night
  • 3-stage powerful heating and ventilation and defroster nozzles on the windscreen
  • Bluetooth radio with hands-free system
  • Automatic air conditioning
  • 12 V socket
  • Sun blind with three different positions
  • Work lights 4x LED Basic (1000 Lumen)
  • Lighting according to road traffic regulations
  • Battery disconnector switch
  • Hydraulically reversible fan
  • Four-part cooling system (hydraulic, charge air, cooling water cooler, air conditioning condenser)
  • Wide-opening engine hood with rubber seal, sight glass for hydraulic oil level and cooling water
  • Combined brake-inch pedal
  • 100% self-locking differential connectible in front and rear axle
  • Electro-hydraulic disc brakes with spring suspension in the front axle, also acting on the rear axle via the universal joint shaft
  • Pendulum pin lubrication line
  • Hydrostatic all-wheel steering with emergency steering properties
  • 3rd control circuit with proportional control and continuous function
  • Pressure release of 3rd control circuit
  • Oil volume for auxiliary control circuits can be set
  • Automatic bucket retract mechanism
  • Automotive infinitely variable, hydrostatic axial piston transmission
  • Dirt wipers, telescopic arm
  • Z-kinematics
  • Hydraulic quick coupler according to ISO 23727 (Volvo TPV system)
  • Operator's manual, service manual

Voliteľné možnosti

  • Rotating beacon (yellow)
  • Rotating LED beacon (yellow)
  • Lighting package (8 work lights - 4 x front, 2 x rear, 2 x side) - No standard working lights
  • Lighting package LED (8 work lights - 4 x front, 2 x rear, 2 x side) - No standard working lights
  • Work light LED mounted to telescopic arm
    • only in association with:
      • Lighting package LED (8 work lights - 4 x front, 2 x rear, 2 x side) - No standard working lights
  • Air-sprung operator's seat with lumbar support (MSG95AL/722)
  • Air-sprung operator's seat with lumbar support and heated seat (MSG95AL/722)
  • Electrically adjustable, heated, exterior mirror with automatic cut-off
  • Cabin, including rear window heating (standard)
  • Carbon filter
  • Mobile phone holder
  • Control panel holder on B-pillar
  • Document box
  • Auxiliary heating, including engine pre-heater, programmable
  • Ecospeed PRO 40 km/h incl. Smart Driving (throttled to 30 km/h or 20 km/h ex works possible)
    • only in association with
      • Load stabilizer (vibration damper)
      • License plate illumination, including license plate bracket in front
      • Engine Deutz TCD 4.1 115kW/156 hp with diesel particulate filter / emission standard: Stage V
  • Ecospeed PRO 40 km/h incl. Smart Driving (throttled to 20 km/h)
    • only in association with
      • Load stabilizer (vibration damper)
      • License plate illumination, including license plate bracket in front
      • Engine Deutz TCD 4.1 115kW/156 hp with diesel particulate filter / emission standard: Stage V
  • Ecospeed PRO 40 km/h incl. Smart Driving (throttled to 30 km/h)
    • only in association with
      • Load stabilizer (vibration damper)
      • License plate illumination, including license plate bracket in front
      • Engine Deutz TCD 4.1 115kW/156 hp with diesel particulate filter / emission standard: Stage V
  • Low-speed device and hand throttle
  • Accelerator pedal mode
    • only in association with
      • Low-speed device and hand throttle
  • License plate illumination, including license plate bracket in front
  • Data confirmation (ABE) for self-propelled working machine (standard) *
  • EC certificate of conformity tractor (167/2013/EC - class T1)
    • only in association with
      • License plate illumination, including license plate bracket in front
      • Outlet for rear attachments, 7-pole
      • In addition, a ball hitch (not a maneuvering hitch) must be selected

* Germany, Luxembourg, Netherlands, Austria, Slovakia, Czech Republic, Switzerland, Estonia, Latvia, Lithuania, Hungary, Italy

Recommended: EC certificate of conformity tractor (167/2013/EC - class T1)

In conjunction with a ball hitch, the rear outlet must always be selected

  • Automatic ball hitch 38 mm - fixed to frame
  • Bearing block for ball hitch couplings, height adjustable (insert for height-adjustable ball hitch coupling required)
  • Insert ball hitch automatic 38 mm for hitch block, height adjustable
  • Insert ball hitch, mechanical, for hitch block height adjustable - 32 mm
  • Insert ball head coupling (K80) for hitch block, height adjustable
  • Insert Piton-Fix for hitch block, height adjustable
  • Insert CUNA D3 for hitch block, height adjustable
  • Insert ball head K50 for hitch block, height adjustable
  • Auto Hitch ball hitch (incl. hydr. control) and tipper connection
    • not with:
      • Industrial protection package
  • Auto Hitch ball hitch (incl. hydr. control) and double-acting rear hydraulic connection including tipper connection
    • not with:
      • Industrial protection package
  • Dual-line, pressure air-brake system
    • not with:
      • Hydrostat 20 km/h incl. Smart Driving
  • Hydraulic trailer brake valve
    • not with:
      • Hydrostat 20 km/h incl. Smart Driving
  • Engine Deutz TCD 4.1 115kW/156 hp with diesel particulate filter / emission standard: Stage V
  • Engine pre-heating, fuel, hydraulic oil (230 V)
  • Load stabilizer (vibration damper)
  • Hydraulic quick coupler, Kramer System HV/TH - L
  • Hydraulic quick coupler, Matbro system
  • Gear pump with increased discharge volume 180 l/min
    • only in association with
      • Engine Deutz TCD 4.1 115kW/156 hp with diesel particulate filter / emission standard: Stage V
  • Filling of the hydraulic system with environmentally-friendly hydraulic oil; PANOLIN Synt46
  • Powerflow 150 l/min
    • only in association with
      • Unpressurized return line, front, including overflow oil line
  • Powerflow 180 l/min including hydraulic pump with increased flow rate 180 l/min
    • only in association with
      • Engine Deutz TCD 4.1 115kW/156 hp with diesel particulate filter / emission standard: Stage V
      • Unpressurized return line, front, including overflow oil line
  • Hydraulically activated control circuit in front (electronic switch-over)
  • Unpressurized return line, front, including overflow oil line
  • Vibrating function tilt cylinder
  • Tipper connection
    • not with:
      • 2 double-acting connections at the rear
  • Pressureless return line, rear
    • only in association with
      • 1 double-acting hydraulic connection rear, including tipper connection
  • 2 double-acting connections at the rear
    • not with:
      • Tipper connection
      • 1 double-acting hydraulic connection rear, including tipper connection
      • Auto Hitch ball hitch (incl. hydr. control) and double-acting rear hydraulic connection including tipper connection
      • Auto Hitch ball hitch (incl. hydr. control) and tipper connection
  • 1 double-acting hydraulic connection rear, including tipper connection
    • not with:
      • 2 double-acting connections at the rear
  • Outlet for rear attachments, 7-pole
  • Outlet for front add-on equipment, 7-pole (2 switch positions)
  • Drive signal outlet, 7-pin
